T54 /T54U Full Touch Screen Mobile Computer
Up to 2.2Ghz Octa-core ARM Processor
Equipped with an Octa-core processor, which consists of eight individual cores, T54/T54U allows for parallel processing. This significantly increases the overall processing power of the device, enabling it to handle more demanding tasks and applications efficiently. T54/T54U enables faster data processing that efficiently handle complex calculations, data manipulation and data-intensive tasks, resulting in quicker response times and improved overall performance.
T54/T54U has an advanced 2D scan engine that sets the industry standard
This cutting-edge technology enables it to efficiently and accurately read various types of barcodes and 2D codes. With its wide scanning range and extended scanning distance, T54/T54U offers enhanced flexibility and speed in scanning applications.
T54 series is lighter, thinner, and more comfortable than traditional handheld devices
Features a 5.45" high definition full touchscreen design with up to 90% screen-to-body ratio and optimized hardware and structure, its performance caters to the specific needs of logistics, retail, public utilities, and the garment industry, enabling operators in these sectors to streamline operations, enhance productivity. T54/T54U is more desirable than traditional ones.
Resources
Specifications for T54 Full Touch Screen Mobile Computer
T54 Full Touch Screen Mobile Computer | T54U Full Touch Screen Mobile Computer | |
Dimension | 158mm(L)×76mm(W)×13.7mm(D) | 159mm(L)×75.9mm(W)×16.5mm(D) |
Weight | 227g/8.01oz(includes battery) | 280g/9.88oz.(includes battery) |
Buttons | Virtual Keys - Menu, Home, Return Physical Keys - Left/Right Scan Key, Power Key, Volume Key | Virtual Keys - Menu, Home, Return Physical Keys - Left/Right Scan Key, Power Key, Volume Key |
User Indicators | Vibration/LED/Audio | Vibration/LED/Audio |
Operating System | Android 9.0 | Android 11.0 |
CPU Model | Octa-Core, up to 2.0GHz,12nm | Octa-Core, up to 2.1GHz,12nm |
Display | 5.45" TFT(LTPS), HD+, 720*1440 | 5.45" TFT(LTPS), HD+, 720*1440 |
Touch Panel | GFF 10-point control, glove operation and wet hand operation available | GFF 10-point control, glove operation and wet hand operation available |
Memory | 4GB RAM+64GB ROM | 6GB RAM+64GB ROM |
SIM | Nano SIM slotx2 | Nano SIM slotx2 |
Extended Storage | Micro SD Card, up to 64GB | Micro SD Card, up to 128GB |
Camera | Front camera 5M; rear camera 13M, PDAF, Quick Focus+Night Shot Light | Front camera 5M, rear camera 13M, PDAF, Quick Focus+Night Shot Light |
Battery/Charger | 5000mAh, non-removable | 6000mAh, removable |
Interface Ports | USB, OTG | USB, OTG |
Motion Sensors | Optical Distance Sensor/Gravity Sensor, Geomagnetic Sensor, Gyroscope Sensor | Optical Distance Sensor/Gravity Sensor/Gyroscope/ Geomagnetic Sensor |
Bluetooth | BT 5.0 | BT 5.0 |
WLAN | Wi-Fi 802.11 a/b/g/n/ac(Dual band: 2.4GHz+5GHz) | Wi-Fi 802.11 a/b/g/n/ac(Dual band: 2.4GHz+5GHz) |
WWAN | GSM: B2/B3/B5/B8 TD-SCDMA: B34/B39 WCDMA: B1/B8 TDD-LTE Bands: B34/B38/B39/B40/B41 LTE_FDD: B1/B3/B5/B8 CA(Carrier Aggregation): B3+B3 downlink 2CA; B1+B3 downlink 2CA | GSM: B2/B3/B5/B8 TD-SCDMA: B34/B39 WCDMA: B1/B8 TDD-LTE Bands: B34/B38/B39/B40/B41 LTE_FDD: B1/B2/B3/B8 CA(Carrier Aggregation): B3+B3 downlink 2CA; B1+B3 downlink 2CA |
GPS | GPS/AGPS/Glonass/Beidou | GPS/AGPS/Glonass/Beidou |
Imager Sensor | 1280x800 pixels | 1280x800 pixels/844*640 pixels |
Field of View | Pitch ±60° Roll(Tilt) 360° Skew(Yaw) ±45° | Pitch ±45° Roll(Tilt) 360° Skew(Yaw) ±60° |
Scan Angles | Horizontal 38.5° Vertical 28.9° | Horizontal 38.5° Vertical 28.9° |
Illumination Element | White LED | White LED |
Aiming Element | Red Cross Laser(650nm) | Red Cross Laser(650nm) |
Symbol Decode Capability | 1D: Codabar, Code 11, Code 128, Code 39, Code93, EAN8, EAN13, GS1 128, Matrix 2 or 5, Trioptic, IATA25, INT25, MSI, STRT25, Telepen, UPC-A, UPC-E0, UPC-E1, NEC25, USPS4CB, HK25 2D: Aztec Code, Grid Matrix, Data Matrix, HanXin Code, Maxicode, MicroPDF, PDF417, QR, RSS, RSL, RSE, Codablock A, Codablock F | 1D: Codabar, Code 11, Code 128, Code 39, Code93, EAN8, EAN13, GS1 128, Matrix 2 or 5, Trioptic, IATA25, INT25, MSI, STRT25, Telepen, UPC-A, UPC-E0, UPC-E1, NEC25, USPS4CB, HK25 2D: Aztec Code, Grid Matrix, Data Matrix, HanXin Code, Maxicode, MicroPDF, PDF417, QR, RSS, RSL, RSE, Codablock A, Codablock F |
Operating Temperature | -4°F~140°F/-20°C~60°C | -4°F~140°F/-20°C~60°C |
Storage Temperature | -40°F~140°F/-40°C~60°C | -40°F~140°F/-40°C~60°C |
Humidity | 0%-95%, non-condensing | 0%-95%, non-condensing |
Drop Spec. | Survive from 4.9ft/1.5m multiple drops | Survive from 4.9ft/1.5m multiple drops |
Sealing | IP65 | IP65 |
Electrostatic Discharge (ESD) | ±8 kv contact discharge ±12kv air discharge | ±8 kv contact discharge ±12kv air discharge |
Software Supported | Generalscan Keyboard Pro Generalscan SDK Demo Generalscan OTA Tools G-Service | Generalscan Keyboard Pro Generalscan SDK Demo Generalscan OTA Tools G-Service |
Decode Range | 7.5mil Code 39 80.0-230.0MM 9.2mil Code 39 70.0-260.0MM 10mil DataMatrix 130.0-160.0MM 12.5mil Code 128 50.0-440.0MM 25mil Code 128 160.0-1380.0MM 20mil QR Code 60.0-605.0MM | |
Packing Contents | T54x1, USB Type-C Cablex1, Adaptorx1, Hand Strapx1, Protective Casex1, Resource Download Cardx1 | T54Ux1, USB Type-C Cablex1, Adaptorx1, Hand Strapx1, Resource Download Cardx1 |
